Name: Asrock A620I Lightning Wifi DDR5 Phantom Gaming AM5 Motherboard
SKU: Y4218657
Availability: InStock

SPECIFICATION

Unique Feature	Superb Productivity
– Dual Channel DDR5
Rock-Solid Durability
– 8+2+1 Power Phase, 60A Dr.MOS with Enlarged Heatsink Armor
– Pre-Installed I/O Shield
– Flexible Integrated I/O Shield
Ultrafast Gaming
– 2.5G LAN, 802.11ax Wi-Fi 6E Module
– ASRock Lightning Gaming Ports
EZ Update
– BIOS Flashback Button
– ASRock Auto Driver Installer
CPU	– Supports AMD Socket AM5 Ryzen 9000, 8000 and 7000 Series Processors*

*The availability of expansion slots may vary by CPU. Please refer toPCIe/M.2 Bandwidth Tablefor details.
Chipset	– AMD A620
Memory
– Dual Channel DDR5 Memory Technology
– 2 x DDR5 DIMM Slots
– Supports DDR5 ECC/non-ECC, un-buffered memory up to 7200+(OC)*
– Max. capacity of system memory: 128GB
– Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules

*Please refer to Memory Support List for more information.
Memory	– Dual Channel DDR5 Memory Technology – 2 x DDR5 DIMM Slots – Supports DDR5 ECC/non-ECC, un-buffered memory up to 7200+(OC)* – Max. capacity of system memory: 128GB – Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules *Please refer to Memory Support List for more information.
BIOS	– 256Mb AMI UEFI Legal BIOS with GUI support
Graphics
Integrated AMD RDNA graphics (Actual support may vary by CPU)
– 1 x HDMI 2.1 TMDS/FRL 8G Compatible, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz
Audio
– 7.1 CH HD Audio (Realtek ALC897 Audio Codec)
– Nahimic Audio
LAN	– 2.5 Gigabit LAN 10/100/1000/2500 Mb/s
– Dragon RTL8125BG
– Supports Phantom Gaming LAN Software
– Smart Auto Adjust Bandwidth Control
– Visual User Friendly UI
– Visual Network Usage Statistics
– Optimized Default Setting for Game, Browser, and Streaming Modes
– User Customized Priority Control
Wireless LAN	– 802.11ax Wi-Fi 6E Module
– Supports IEEE 802.11a/b/g/n/ac/ax
– Supports Dual-Band 2×2 with extended 6GHz band*support
– 2 antennas to support 2 (Transmit) x 2 (Receive) diversity technology
– Supports Bluetooth 5.2 + High speed class II
– Supports MU-MIMO

*The Wi-Fi 6E module is supported by Microsoft Windows11 only. There is no driver available for Windows10. The availability of the 6GHz band will depend on the different regulation status of each country and region. It will be activated (for supported countries) through WindowsUpdate and software updates once available.
A 6GHz compatible router is required for 6E functionality.
Slots	CPU:
– 1 x PCIe 4.0 x16 Slot (PCIE1), supports x16 mode*
Chipset:
– 1 x Vertical M.2 Socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module*
– 15 Gold Contact in VGA PCIe Slot (PCIE1)

*Supports NVMe SSD as boot disks
Storage	CPU:
– 1 x Hyper M.2 Socket (M2_1, Key M), supports type 2280 PCIe Gen4x4 (64 Gb/s) mode*
Chipset:
– 1 x Ultra M.2 Socket (M2_2, Key M), supports type 2280 PCIe Gen3x4 (32 Gb/s) mode*
– 2 x SATA3 6.0 Gb/s Connectors

*Supports NVMe SSD as boot disks
RAID	– Supports RAID 0 and RAID 1 for SATA storage devices
– Supports RAID 0, RAID 1 and RAID 10 for M.2 NVMe storage devices*

*Requires additional M.2 NVMe expansion cards to support RAID 10
USB	– 1 x USB 3.2 Gen2 Type-C (Rear)
– 2 x USB 3.2 Gen2 Type-A (Rear)
– 1 x USB 3.2 Gen1 Type-A (Rear)
– 1 x USB 3.2 Gen1 Type-C (Front)
– 2 x USB 3.2 Gen1 Type-A (Front)
– 4 x USB 2.0 (2 Rear, 2 Front)

*All USB ports support ESD Protection
Connector	– 2 x Addressable LED Headers*
– 2 x CPU/Water Pump Fan Connectors (4-pin) (Smart Fan Speed Control)**
– 1 x Chassis/Water Pump Fan Connector (4-pin) (Smart Fan Speed Control)***
– 1 x 24 pin ATX Power Connector
– 1 x 8 pin 12V Power Connector (Hi-Density Power Connector)
– 1 x Front Panel Audio Connector
– 1 x USB 2.0 Header (Supports 2 USB 2.0 ports)
– 1 x USB 3.2 Gen1 Header (Supports 2 USB 3.2 Gen1 ports)
– 1 x Front Panel Type C USB 3.2 Gen1 Header

*Support in total up to 5V/3A, 15W LED Strip
**CPU_FAN1/WP and CPU_FAN2/WP support the fan power up to 2A (24W).
***CHA_FAN1/WP supports the fan power up to 2A (24W).
CPU_FAN1/WP, CPU_FAN2/WP and CHA_FAN1/WP can auto detect if 3-pin or 4-pin fan is in use.
Rear Panel I/O	– 2 x Antenna Ports
– 1 x HDMI Port
– 2 x USB 3.2 Gen2 Type-A Ports (10 Gb/s)*
– 1 x USB 3.2 Gen1 Type-A Port*
– 1 x USB 3.2 Gen2 Type-C Port (10 Gb/s)
– 2 x USB 2.0 Ports
– 1 x RJ-45 LAN Port
– 1 x BIOS Flashback Button
– HD Audio Jacks: Line in / Front Speaker / Microphone

*USB32_23 are Lightning Gaming Ports.
Software and UEFI	Software
– ASRock Motherboard Utility (Phantom Gaming Tuning)
– ASRock Phantom Gaming LAN Software
– ASRock Polychrome SYNC*
UEFI
– ASRock Full HD UEFI
– ASRock Auto Driver Installer
– ASRock Instant Flash

*These utilities can be downloaded from ASRock Live Update & APP Shop.
Accessories	– 1 x User Manual
– 2 x SATA Data Cables
– 2 x ASRock WiFi 2.4/5/6 GHz Antennas
– 1 x Screw for M.2 Socket
Form Factor	– Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
– 8 Layer PCB
OS	– Microsoft Windows10 64-bit / 11 64-bit
Certifications	– FCC, CE
– ErP/EuP ready (ErP/EuP ready power supply is required)
